    Production Capacity
    20 Sets/ Year
    HS Code
    8479819000
    Origin
    China
    Trademark
    HiTO

    Product Overview


    The production of HiTo Color Painting Line adopts advanced technology and latest machines & equipment. The product meets with the global set standards in all respects, such as performance, service life, usability, and so on. HiTo Engineering's Color Painting Line can be widely used in various fields. Our Color Painting Line have been through strict quality test before they are packed.


    Product Description



    Weifang HiTo Equipment Engineering Co.,Ltd


    Innovation is our Mission. It is key for providing our customers with a competitive advantage. Our innovative engineering team applies our technology to offer a tailor made solution to your individual requirements consistent with your preferences, production goals and budgets.

    The competitive advantage of HiTo stems from being able to offer the world's best technology at competitive pricing, with the backup of full & ongoing specialist support. In short, we offer a world class supply solution that is second to none.


    The color coating unit adopts double-coating double-baking model and hot air circulation heating process.
    1. Material of base plate: electro-galvanized plate, hot-dip galvanized plate, hot dip Al-Zn plate, cold-rolled steel plate , Aluminum Coils etc.
    2. Raw material:cold rolled strip,GI,GL,aluminum strip, 3-15Tons
    3. Thickness of strip steel: 0.12-1.8mm, Width of strip steel: 600-1650mm
    4. Process speed: 30 - 200m/min
    5. Production capacity: 30,000-300,000 Tonnes/year

    China Color Coating Production Line for Galvanized Steel Coil
    Process Flow of the color coating line:

    China Color Coating Production Line for Galvanized Steel Coil
    We provide Pattern Printing System to produce pattern color coated steel, like the mood grain, marble/brick pattern and so on.

    China Color Coating Production Line for Galvanized Steel Coil

    We offer the following services to our customers:

    · Project feasibility
    · Equipment design
    · Installation and commissioning
    · Technology transfer
    · Training of operators and production personnel
    · Product testing
    · Downstream Equipment
    · Ongoing technical support
    Nominal Thickness Allowable Deviation of Thickness in Case of the Following Thicknesses
    General Precision PT.A High Precision PT.B
    ≤1200 >1200-1500 ≤1200 >120-1500
    0.20-0.40 ±0.05 ±0.06 ±0.03 ±0.04
    >0.40-0.60 ±0.06 ±0.07 ±0.04 ±0.05
    >0.60-1.0 ±0.07 ±0.08 ±0.05 ±0.06


    Factory


    China Color Coating Production Line for Galvanized Steel CoilChina Color Coating Production Line for Galvanized Steel CoilChina Color Coating Production Line for Galvanized Steel CoilChina Color Coating Production Line for Galvanized Steel CoilChina Color Coating Production Line for Galvanized Steel Coil
    Recently, we have undertaken the site of the project



    China Color Coating Production Line for Galvanized Steel Coil

    China Color Coating Production Line for Galvanized Steel Coil
    China Color Coating Production Line for Galvanized Steel Coil


    FAQ

    Give us the connected electrical load of machine in KW
    A: 850-1000 Kw

    We insist all program software and HMI text should be in English language not in chinese.
    A: Yes. All program software and HMI text are English language.

    Can I choose a configuration
    A:Yes,sure

    China Color Coating Production Line for Galvanized Steel Coil
