    Warranty
    One Year
    After-sales Service
    Install, Debug, Operator training
    Coils
    Steel, Alu. Ss, Cr, Gi, Gl
    Delivery Time
    3-5 Months
    Raw Material
    Gi, Gl, Al, Ss
    Capacity
    30000-300000tons
    Width
    700-1550mm
    Thickness
    0.15-1.5mm
    Production Capacity
    20 Sets/ Year
    HS Code
    8479819000
    Origin
    China
    Trademark
    HiTO
    Specification
    1500CBM
    Transport Package
    Containers
    Speed
    30-200mpm
    Condition
    New
    Certification
    ISO
    Substrate
    Steel
    Coating
    Coil Coating
    Type
    Coating Production Line

    Quick Overview


    HiTo Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/60000tons Ccl is manufactured from the best quality materials that have passed through our strict materials selection system. Its quality is highly valued in our factory. The Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/60000tons Ccl produced by our company is widely used. We are able to provide complete service system from pre sales to after sales.

    Product Description


    The color coating unit adopts double-coating double-baking model and hot air circulation heating process.


    HiTo EQUIPMENT PARAMETERS:

    1. Material of base plate: electro-galvanized plate, hot-dip galvanized plate, hot dip Al-Zn plate, cold-rolled steel plate , Aluminum Coils etc.
    2. Raw material:cold rolled strip,GI,GL,aluminum strip
    3. Thickness of strip steel: 0.12-1.8mm, Width of strip steel: 600-1650mm
    4. Outer diameter of steel coil: φ800-2000mm
    5. Process speed: 30 - 200m/min
    6. Coating thickness : 5-25μm for the single-layer dry film on the front face (regulated as required)                                                                      5-15μm for the single-layer dry film on the back face (regulated as required)
    7. Production capacity: 30,000-300,000 Tonnes/year
    8. Energy type: electricity, natural gas, liquefied petroleum gas,  etc.



    This is HiTo completed DUBAI Industry City color coating line project:

    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/60000tons Ccl
    Process Flow of the color coating line:

    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/60000tons Ccl

    HiTo provides Pattern Printing System to produce pattern color coated steel, like the mood grain, marble/brick pattern and so on.


    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/60000tons Ccl

    HiTo offers the following services to our customers:

    · Project feasibility
    · Equipment design
    · Installation and commissioning
    · Technology transfer
    · Training of operators and production personnel
    · Product testing
    · Downstream Equipment
    · Ongoing technical support


    Nominal Thickness Allowable Deviation of Thickness in Case of the Following Thicknesses
    General Precision PT.A High Precision PT.B
    ≤1200 >1200-1500 ≤1200 >120-1500
    0.20-0.40 ±0.05 ±0.06 ±0.03 ±0.04
    >0.40-0.60 ±0.06 ±0.07 ±0.04 ±0.05
    >0.60-1.0 ±0.07 ±0.08 ±0.05 ±0.06


    HiTo Factory
    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/ CCL - Color Precoated Line 11

    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/ CCL - Color Precoated Line 12
    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/ CCL - Color Precoated Line 13
    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/ CCL - Color Precoated Line 14
    HiTo Engineer Team
    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/ CCL - Color Precoated Line 15
    Recently,HiTo has undertaken the site of project
    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/ CCL - Color Precoated Line 16
    HiTo After-sales Team
    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/ CCL - Color Precoated Line 17


    Pre-Coated Metal Strip Coil Line/Precoated Line/Color Precoated Line/60000tons Ccl


    FAQ

     Give us the connected electrical load of machine  in KW
    A:  850-1000 Kw

    We insist all program software and HMI text  should be in English language not in chinese.
    A: Yes. All program software and HMI text are English language.

    Can I choose a configuration
    A:Yes,sure
