Top Colour Coating Line Specification Company

Product details of the colour coating line specification

Product Specification

Origin: China

Condition: New

Coating: Coil Coating

Substrate: Steel

Specification: 1600CBM

Product Information

HiTo Engineering colour coating line specification is manufactured with exquisite development and strict production workmanship. The form of this product harmonizes with the function. Weifang HiTo Equipment Engineering Co.,Ltd has abundant funds and strong scientific manpower.

Product Description

Weifang HiTo Equipment Engineering Co.,Ltd

Innovation is our Mission. It is key for providing our customers with a competitive advantage. Our innovative engineering team applies our technology to offer a tailor made solution to your individual requirements consistent with your preferences, production goals and budgets.The competitive advantage of HiTo stems from being able to offer the world's best technology at competitive pricing, with the backup of full & ongoing specialist support. In short, we offer a world class supply solution that is second to none.

The color coating unit adopts double-coating double-baking model and hot air circulation heating process.

1. Material of base plate: electro-galvanized plate, hot-dip galvanized plate, hot dip Al-Zn plate, cold-rolled steel plate , Aluminum Coils etc.
2. Raw material:cold rolled strip,GI,GL,aluminum strip, 3-15Tons
3. Thickness of strip steel: 0.12-1.8mm, Width of strip steel: 600-1650mm
4. Process speed: 30 - 200m/min
5. Production capacity: 30,000-300,000 Tonnes/year

Process Flow of the color coating line: We provide Pattern Printing System to produce pattern color coated steel, like the mood grain, marble/brick pattern and so on. We offer the following services to our customers: · Project feasibility · Equipment design · Installation and commissioning · Technology transfer · Training of operators and production personnel · Product testing · Downstream Equipment · Ongoing technical support

Nominal Thickness	Allowable Deviation of Thickness in Case of the Following Thicknesses
	General Precision PT.A		High Precision PT.B
	≤1200	>1200-1500	≤1200	>120-1500
0.20-0.40	±0.05	±0.06	±0.03	±0.04
>0.40-0.60	±0.06	±0.07	±0.04	±0.05
>0.60-1.0	±0.07	±0.08	±0.05	±0.06

Factory Recently, we have undertaken the site of the project FAQ Give us the connected electrical load of machine in KW A: 850-1000 Kw We insist all program software and HMI text should be in English language not in chinese. A: Yes. All program software and HMI text are English language. Can I choose a configuration A:Yes,sure

Company Feature

• Our products are mainly sold to major cities in China and exported to countries and regions such as Asia, Europe and Africa.
• HiTo Engineering's location enjoys a comprehensive traffic network, which is good for the distribution of products.
• Our company adheres to the service thinking mode of 'looking at the problem from our customer's perspective'. Besides, we always keep in mind the principle that 'there is no small problems of customers'. In this way, we can provide intimate services for the consumers.
• HiTo Engineering has professional sales and technical teams. We can provide quality products, technical support, and sound after-sales services for customers.
We are waiting for consulting from new and old customers!
